mt-s805 is a quad core android ott/iptv set-top box.it is designed for isps,ott
operators and content aggregators that provide services based on iptv,ott and vod.
arm cortex-a5 quad core cpu,android 4.4
1080p hd resolution output
drm:widevine,playready,verimatrix,marlin
support pppoe、dhcp、lan multiple access methods.
support ipv4
support ieee 802.11b/g/n
support bluetooth 4.0
support 10/100mbps ethernet rj45 port
support  2*usb port
support 1* cvbs
support 1*spdif
support one micro sd card interface


product specification
processor cpu arm cortex-a5 quad core cpu up to 1.5ghz(dvfs)
gpu quad-core arm mali-450 gpu up to 600mhz (dvfs)
dual geometry processors
system ui android
os android 4.4
memory dram 2gb,ddr3
flash 8gb,emmc
interface power 12v,1a
usb usb2.0 x2,support mouse&keyboard
ethernet rj45
hdmi hdmi1.4,video output
spdif fiber audio output
sd card tf card
mini av 1 to 3 (3.5mm)
network wi-fi wi-fi 2.4ghz 300m ieee 802.11b/g/n
bluetooth bluetooth 4.0
ir internal ir receiver
ethernet rj45 interface 10m/100m ieee 802.3u
video format avi,flv,iso,m2ts,mkv,mov,mp4,mpg,mpeg,rm,rmvb,ts,vob,wmv,dat,3gp,divx,f4v,asf,m2v etc.
decoder h.265 1080p@60fps, h.264 avc/vc-1, wmv/vc-s, avs, webm, rmvb, hd mpeg 1/2/4, mjpeg, h.263, divx 3/4/5/6, xvid, realvideo 8/9/10,vp6/8
max resolution 1080p
audio format mp3, wma, wav, ogg, m4a, mp4, aac, ape, flac, mp1/2 etc.
decoder mpeg1/2/4, mp3, aac/aac , wma/wma-pro,  flac, ogg etc.
support dobby(optional)&dts(optional)
photo format gif,jpg,jpeg,bmp,png etc.
power
consumption
consumption 8w max
environment operation
temperature
0~40℃
humidity 5~95(%rh)
accessory
list
accessory 2k iptv box
  remote control
  battery
  power adapter
  hdmi cable
  user manual
  size 110*110*21.5mm
  material plastic
  color black,white,
accessory
list
accessory 4k iptv box
remote control
battery
power adapter
hdmi cable
mini av cable
user manual
